Self-locking cable Ties

Short Description:

Material:Nylon 66, 94V-2Operating Temperature:-40℃-85℃Color:Natural,UV black and others are available.Certificate: UL.E220676Package:100pcsITEM: HS-60A,80A,100A,120A,150A,200A,120B,150B,200B,250B,300B,370B,120C,150C,190C,200C,250C,300C,350C,370C,400C,430C,500C,530C,150D,200D,250D,300D,350D,370D,400D,450D,500D,550D,430DL,450DL,550DL,600DL,650DL,700DL,760DL,810DL,920DL,1168DL,500EL,800EL,550FL


Product Detail

Product Tags

Keywords: self locking nylon cable zip ties, self locking nylon cable zip ties, cable zip tie, cable zip tie, UL nylon cable ties, UL nylon cable ties, hdmi cable monster cable, hdmi cable monster cable, hdd cable connector cable, hdd cable connector cable, pa66 nylon cable tie, pa66 nylon cable tie

Material:Nylon 66 (PA6,6), UL94V-2
Operating Temperature:-40℃-85℃
Color:Natural,UV black and all colors are available.
Certificate: UL.E220676; CE, ROHS, REACH
Package:100pcs or Special request Packing available
Type: self locking cable ties, Nylon zip ties, Nylon cable ties, Standard PA6,6 cable ties, UL plastic ties, Wahsure cable zip ties, wire ties, UL nylon cable ties, nylon cable ties colors, Colors nylon cable zip ties

Features
*
Nylon Standard cable ties, ideal for industrial, home use, they are used in the widest range of operations – from the simple bundling of cables with cable ties to the absolutely specific use of cable ties under extreme conditions.
*The design of the head guarantees a high tensile strength while allowing a very low insertion force, in good handle feel, easy operation.
*Top popular cable tie series

With its high-quality cable ties , Wahsure provides system solutions which can meet practically any challenge. They do not just fulfil the most up to date requirements for cable ties and cable tie systems, but Wahsure constantly pushes back the boundaries of what is technologically possible with its fixing elements. In these ways, new cable tie solutions or new fixing elements are developed jointly with customers which can also stand up to the most extreme and exceptional environmental influences.

ITEM NO. : HS-80A


Operating Temp.-40~85
-40~185
Min. Installation Temp.0
32
Lengthmm80
Inch3.2
Widthmm2.5
Inch0.1
Max. Bundle Dia.mm16
Inch0.63
Min. Loop Tensile StrengthN78.4
KG8
LBS18



Other size

Specification Data:
ITEM NOLENGTH (MM)WIDTH (MM)Max. Bundle DiaTensile Strength
INCHMM(mm)LBSKGS
HS-60A2 3/8"602.511188
HS-80A3 3/16"802.516188
HS-100A4"1002.522188
HS-120A4 3/4"1202.530188
HS-150A6"1502.535188
HS-160A6 1/4"1602.540188
HS-200A8"2002.550188
HS-120B4 3/4"1203.5304018
HS-150B6"1503.5354018
HS-180B7"1803.5424018
HS-200B8"2003.5504018
HS-250B10"2503.5654018
HS-280B11"2803.5704018
HS-300B12"3003.5824018
HS-370B14 1/2"3703.51024018
HS-120C4 3/4"1204.6245022
HS-150C6"1504.6355022
HS-190C7 1/2"1904.6465022
HS-200C8"2004.6505022
HS-250C10"2504.8655022
HS-280C11"2804.8705022
HS-300C12"3004.8825022
HS-350C14"3504.8905022
HS-370C14 1/2"3704.81025022
HS-400C16"4004.81055022
HS-430C17"4304.81105022
HS-450C17 3/4"4504.81305022
HS-500C20"5004.81405022
HS-530C20 4/5"5304.81475022
HS-300DS12"3006.8829040
HS-370DS14 1/2"3706.81029040
HS-150D6"1507.63312055
HS-200D8"2007.65012055
HS-250D10"2507.66312055
HS-300D12"3007.68212055
HS-350D14"3507.69012055
HS-370D14 1/2"3707.610212055
HS-400D16"4007.610512055
HS-450D17 3/4"4507.611812055
HS-500D20"5007.615012055
HS-550D22"5507.616012055
HS-430DL17430911217580
HS-450DL17 3/4"450911817580
HS-550DL22"550916017580
HS-600DL24"600917017580
HS-650DL25 9/16"650919017580
HS-700DL27 1/2"700920017580
HS-760DL30"760922517580
HS-810DL32"810923917580
HS-920DL36"920926517580
HS-1168DL461168936017580
HS-500EL20"5001015020091
HS-800EL31 1/2"8001023020091
HS-550FL22"55012.7160250114
